Size :M (17")
Color(s): Satin Graphite, Dark Teal
Frame: Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Fork: SR Suntour SF19-XCT30-HLO-DS-29, hydraulic lockout, 100mm
Crankset: Prowheel, 42/34/24T
Bottom Bracket: Sealed cartridge bearing
Pedals: Resin platform
Front Derailleur: Microshift FD-M20
Rear Derailleur: SRAM X4
Shifters: SRAM X4, 3 x 8-speed
Cassette: Sunrace CSM66, 11-34T
Chain: KMC HV700
Wheelset: WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hubs, black spokes
Tires: WTB Ranger Comp, 29" x 2.25", 27tpi
Brakeset: Tektro HD-M275, 180/160mm rotors
Brake Levers: Tektro HD-M275
Headset: 1 1/8" sealed bearings
Handlebar: Fuji flat bar, alloy, 710mm
Stem: Fuji, forged aluminum, +/-6°
Grips: Fuji Performance Grip
Saddle: Fuji Performance Saddle
Seat post: Fuji, alloy, 30.9mm
Geometry
View Size Guide
Size XS S M L
Bike Size 17"
A. Seat Tube, Center To Top 310 370 420 470
B. Top Tube, Effective 562 581 601 629
C. Head Tube Length 95 100 110 120
D. Seat Tube Angle 73° 73° 73° 73°
E. Head Tube Angle 69.5° 69.5° 69.5° 69.5°
F. Chainstay Length 440 440 440 440
G. Wheelbase 1068.5 1087 1109 1137
H. Bottom Bracket Drop 45 45 45 45
I. Fork Offset 42 42 42 42
J. Stack 596 600 610 619
K. Reach 380 397 415 440
L. Standover 737 767 795 823
